Specifications

Engine Control?

• Start preparation (preheating or prelubrication)
• Start/stop sequences with selectable no. of start attempts
• Local or remote start/stop
• Stop sequence with cool down
• Selectable running feedback

Generator protection (ANSI)

• Over-/ undervoltage (27/59)
• Over-/ underfrequency (81)
• Overcurrent (51)

Voltage regulation

• Ph-N or Ph-PhAC Voltage sensing
• U/F Funcion
• Voltage setpoint is adjustable between 90 up to 480 VAc
• Voltage stability setpoint
• Softstart function
• Accuracy

Excitation

• Excitation system : SHUNT
• Maximum excitation current : 4 A
• Excitation forcing: 7 A, 10 seconds
• No load : 0.6 - 1 A
• Exciter field resistance : 10 - 30 Ohms
• Supply voltage: 90 VAC - 227 VAC @ 50 Hz or 60 Hz

Power Supply

• DC 8 V to 35 V, Continuous Power Supply
• Continuous DC -35 V reverse protection
• Power consumption < 3 W?

Dropout cranking?

• Able to survive 0 V for 10 m

Load dump

• ISO 7637-2 (24DVC system – Pulse test 5)
• Power supply ports: 123 V / 1 W / 100 ms – 174 V / 8 W / 350 ms



LEROY-SOMER UTILITY SOFTWARE

Complete control & monitoring software providing access to all settings.

• Logic sequences programming for incidents & events handling
• Oscilloscope capability allowing signals analysis and alarms setup
• Data monitoring & broadcasting capabilities
• User profiles and factory presets management



Generator Sensing

Voltage

• 3-phase / 4 wires: 15 – 277 VAC (Ph-N)
• 3-phase / 3 wires: 30 – 480 VAC (Ph-Ph)
• Single phase / 2 wires: 15 – 277 VAC (Ph-N)

Impedance: 1.2 – 1.5 MW
Accuracy: Class 2.0 (IEC/EN 60688)

Frequency

• Presets: 50 & 60 Hz
• Range: 45-75 Hz

Current

• 5A / 1A (rated) Class II

Current overload

• ž2 x ln, 60 seconds
• 4 x ln, 10 seconds?



Outputs

Digital outputs?

• Fuel : 6 A
• Starter : 6 A
• Auxiliary x3 : 500 mA

Inputs

RMI inputs

• Range: 0-7500ohms with wire fail detection
• Class 2: 0-2500 Ohm
• Class 4: 2500-7500 Ohm

Analog inputs

• Current: 4-20mA
• Impedance: 100 ohms
• Class 2 with wire fail detection

Binary input

• Dry contact inputs, with cable supervision
• Active from 0 to 1.6 VDC
• Inactive from 1.7 to power supply voltage

MPU input

• Frequency: 10 to 10KHz
• Voltage: 1.5 to 25 VAC RMS
• Accuracy 1/10 [Hz] @ 10 to 99.9 [Hz], 1 [Hz] @ 100 to 10000 [Hz]



Environment

EMC marking

• IEC/EN 60255-26

Protection

• Front panel : IP65 (IEC/EN 60529)
• Terminals: IP20
• Self-extinguishing plastics

Humidity

• 95%RH, IEC 60068-2-30, test Db IEC 60255-1

Vibration

• 3…13.2 Hz: 2 mmpp. 13.2…100 Hz: 0.7g (peak) - (IEC 60068-2-6 and IACS UR E10)
• 3…25 Hz: 3,2 mmpp. 25…100 Hz: 4.0g (peak) - (IEC 60068-2-6 and IACS UR E10)
• 10…60 Hz: 0.15mmpp. 60…150 Hz: 1g (peak) - (IEC 60255-21-1 - Response class 2)
• 10…150 Hz: 2 g. To IEC 60255-21-1 Endurance (class 2)

Shock

• 50g, 11msec, half sine – IEC 60068-2-27, test Ea
• Tested with 3 impacts in each direction in all 3 axes. Total 18 per test. IEC 60255-21-2 10g EUT ON, 30g EUT OFF

Bump

• 20 g, 16msec, half sine – IEC 60255-21-2 (Class 2)

Safety

• Installation category (overvoltage category) III, 300V
• Pollution degree 2 (IEC 60255-27)



Miscellaneous

Dimensions ž Width : 130 mm ž Height : 110 mm ž Depth : 67 mm ž Weight: 410 grams ž Panel cut out: 112 x 92 mm Temperature ranges žOn-duty : -30 to +70°C Storage: -40 to +85°C ??? Altitude ž2000 m ? Accessories USB cable, 3m

Display ž Type: Backlit LCD ž Resolution: 128x64 pixels ž Size: 53x28 mm Available variants ControlReg 200 : Auto Start, island mode ControlReg 200P : Auto Mains Failure ? Service Port USB-B plug ??
