Kato Engineering offers a complete line of high frequency (400 Hz) generators. These units provide economical power for grounded aircraft's navigational equipment, ground power and military support products.
Voltage range: 115/200, 120/208, 240/416
Phase: 3
Power factor: 0.8
| Pole | RPM | kVA |
|---|---|---|
| 26 | 1846 | up to 312.5 |
| 24 | 2000 | up to 156 |
| 20 | 2400 | up to 156 |
| Other ratings are available upon request. | ||
Exciter: Brushless rotating type
Enclosure: Open dripproof
Bearings: Double shielded re-greaseable ball type
Driver adaptation: All units are available in a two-bearing design. Typically, units rated 100 kW and lower with 26 or fewer poles can be supplied in a single-bearing design for direct connection to the SAE engine drive arrangements.
Rotor and stator insulation: Class F or Class H with resin vacuum-pressure impregnated (VPI)
Efficiency: 82% to 94% depending upon kW rating
Standards & certifications available
