Kato Engineering low voltage generators range up to 1000 V.
The specially designed insulation system used on these generators guarantees high opposition to chemicals and moisture in hostile environments and a long generator life.
We offer the following specifications:
Power Rating:
265-2700 kW 4 Pole
175-2400 kW 6 Pole
275-2960 kW 8 Pole
375-3325 kW 10 Pole
Frequency: 60 Hz or 50 Hz, three phase (optional six phase)
Speed: @ 50/60 Hz: 1500/1800 RPM, 1000/1200 RPM, 750/900 RPM, 600/720 RPM
Rotor and stator insulation: Class F or Class H with 100% solids epoxy resin vacuum-pressure impregnation (VPI)
Efficiency: 88% to 97% depending on kW rating, operating speed and voltage.
Enclosures: Open drip proof is standard, with the following options available:
Standards & certifications available
Click here for more design and construction options and features.
